Technische Beschreibung

• RAHMEN

  KELLYS TYGON R-series - advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / integrated removable battery, 1.5" tapered HT, 12x148 mm Boost thru axle
• Gabel

  SR SUNTOUR Raidon 34 LOR DS (29") Boost, 120 mm, air / 15 mm thru axle
• Displey

  PANASONIC Bluetooth® 5.0 navigation Side Color Display
• Federweg vorne

  120 mm
• Motor

  PANASONIC GX Ultimate, 95 Nm, 36 V
• Akku

  KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by Kellys-BMZ
• Schaltwerk (hintere Schaltung)

  SHIMANO Deore M5120 (direct mount)
• Schaltwerk

  SHIMANO Deore SL-M4100-R Rapidfire Plus (I-Spec EV)
• Bremse vorne

  SHIMANO MT200 Hydraulic Disc 180 mm
• Bremse hinten

  SHIMANO MT200 Hydraulic Disc 180 mm
• Bremshebel

  SHIMANO BL-MT200
• Kurbel

  SAMOX (34T) - length 170 mm
• Lagersatz

  FSA 1.5 semi-integrated
• Pedale

  plastic
• Patrone

  SHIMANO CS-M4100-10 (11-46T)
• Kette

  KMC e10T (116 links)
• Anzahl der Geschwindigkeiten

  10
• Lenker

  KLS Active RiseBar - diam 31.8 mm / rise 18 mm / width 720 mm
• Vorbau

  KLS Active - diam 28.6 mm / bar bore 31.8 mm / 6° / length 80 mm
• Sattelstütze

  KLS Active - diam 30.9 mm / length 350 mm
• Sattel

  SELLE ROYAL Vivo
• Fahrradgriffe

  KLS Poison OneLockon
• Vorderradnabe

  SHIMANO MT400-B Disc Center Lock (15x110 mm / 12x148 mm / 32 holes)
• Hinterradnabe

  SHIMANO MT400-B Disc Center Lock (15x110 mm / 12x148 mm / 32 holes)
• Felgen

  KLS Valor 3 Disc 622x30 (32 holes)
• Reifen

  SCHWALBE Nobby Nic Performance 60-622 (29"x2.35) ADDIX, folding
• Radgröße

  29"

Weiteres

• Produktcode

  N24000006
