Technische Beschreibung

• RAHMEN

  Full carbon with 150mm travel (integrated battery, internal cable routing)
• Gabel

  Rock Shox 35 Gold (Travel: 150mm, tapered, rebound and lockout adjustments)
• Displey

  STEPS KSCE7000
• Federweg vorne

  150 mm
• Fedrweg hinten

  Rock Shox Deluxe Select+ RT 230x60mm
• Motor

  Shimano DUEP8 (Power 250W, max torque: 85Nm, max support up to 200%)
• Akku

  Darfon (Capacity: 630Wh, integrated)
• Schaltwerk (hintere Schaltung)

  Sram GX 12 speed eagle 12 speed
• Schaltwerk

  Sram NX eagle, 1×12
• Bremse vorne

  Clarks M4 180mm disc brakes
• Bremse hinten

  Clarks M4 180mm disc brakes
• Kurbel

  FSA EP8 chainring 36t, length 175mm
• Lagersatz

  FSA Orbit 1.5E ZS tapered
• Pedale

  Wellgo M272T DU
• Kette

  KMC e12,Chain guide: Shimano STEPS SM-CDE70
• Lenker

  FSA V-Drive, 15mm rise, 740mm width, 31.8 clamp
• Vorbau

  FSA V-Drive 60/31.8mm, length: 60mm, 31.8 clamp
• Sattelstütze

  Kind Shock e20i, 375/31.6mm, travel 100mm
• Sattel

  Prologo Kappa RS
• Vorderradnabe

  HBC Pro 15x110mm
• Hinterradnabe

  HBC Pro 12x148mm, HG body
• Felgen

  ERX 29” front, 27.5” rear 32h
• Reifen

  Schwalbe Nobby Nic 29×2.6” front 27.5×2.6”rear, TLE
• Radgröße

  29” front, 27.5” rear
• GEWICHT

  23.2 kg

Weiteres

• Produktcode

  N24000287
